Description

THIS IS A MOST USEFUL R-1100 C ELECTRIC MUFFLE KILN WITH STANDARD P.I.D. TEMPERATURE CONTROLLER AND 11.5 CUBIC LITER SPACIOUS CHAMBER THAT IS ESPECIALLY DESIGNED FOR WORKING WITH ALL TYPES OF MATERIALS ON TEMPERATURES UP TO 1100 C (2012 F). FOR YOUR SAFETY THIS KILN HAVE A SECURE MECHANISM THAT WILL DISCONNECT THIS KILN’S POWER SUPPLY FROM ITS HEATING ELEMENT/S IF DOOR OF THIS KILN IS OPEN OR CLOSED NOT PROPERLY. IT HAS ONE 16-MM HOLE WITH A STAINLESS STEEL SHUTTER ON THE DOOR TO SEE FIRING OBJECT/S DURING ALL FIRING PROCESS. THIS KILN HAS ALSO A DIGITAL, OVER/LOW-TEMPERATURE REGULATION SECURE SYSTEM TO HOLD SAME TEMPERATURE DURING THE WHOLE SOAKING PROCESS AND A SMOOTHING CIRCUIT DIGITAL GUARD FOR ACCURATE READING AND STABILITY WORK OF THE TEMPERATURE CONTROLLER ON FLUCTUATIONS OF ELECTRICITY THAT IS VERY IMPORTANT OPTION FOR MOST MATERIALS.

__________________________________________________________________________________________________
ATTENTION!
The door of this kiln was accidentally damaged and now has two minor cracks.
Despite this, the kiln is fully suitable for operation and is covered by the full manufacturer’s warranty.
Please carefully review the real photos attached before purchasing.
This item is sold as is. No returns will be accepted.
__________________________________________________________________________________________________

Technical specification:

– Brand name: Technical Supermarket;
– Model: R-1100C;
– CE, UKCA, FCC, CPSA, ISO:9001 certified;
– 230 Vac +/-10% with a standard EU, UK or AU electrical plug (on request);
– Single phase, 12 A;
– 2600 Watt;
– No asbestos at all;
– Maximum working temperature – 1100 C (2012 F);
– Heating time to temperatures higher 1000 C – 90 minutes;
– Continuously working time on temperatures higher 1000 C = 8 hours. Below 1000 C = 24 hours.
– Kiln dimensions in MM (inch): H380 x W380 x L660 (14/2.5″ x 14.2/5″ x 26″);
– Chamber dimensions in MM (inch): L290 x W200 x H200 (11.5″ x 8″ x 8″ and 14″ Diagonal);
– Chamber volume: 11.5 cubic liter;
– Standard PID temperature controller (no time setting) that will allows you to pre-set and automatically reach and hold (soak) at required time any single temperature between a room temperature and 1100 C.
– Safety switch mechanism for disconnecting heating elements of the kiln from a power supply if door is open or closed not properly;
– One ventilation hole with stainless steel shutter on the door;
– Positions of two heating elements: right and left;
– Digital over/low-temperature regulation secure system;
– Smoothing circuit (stability work control) digital guard;
– Industrial graded K-thermocouple on right wall of the kiln (1.2 mm wire);
– Calibrated on five points: 100 C; 240 C; 450 C; 830 C and 1075 C;
– Estimated accuracy of SOAKING temperature: +/- 1 C;
– You will require a standard screw-driver to fix electrical box with temperature controller, thermocouple and safety switch’s mechanism of this kiln by few screws (supplied).
– Weight – 39 Kg (46 KG with wooden box);
– Cable – 2.5 M.
– Sold as is. No return will be accepted.

Delivery specification:

– This R-1100 C – 230V electric muffle kiln;
– K-thermocouple;
– Safety switch mechanism;
– Electrical box with standard PID temperature controller and a secure switch;
– User manual and a temperature controller downloadable instruction;
– One yaer standard manufacturer warranty with professional after-selling services include warranty, parts-by-post worldwide and online help by email or/and Teams, WA, Zoom.
